ISWH不銹鋼離心泵結合國外領先制泵技術，在普通臥式泵基礎上派生出適用腐蝕性液體輸送的不銹鋼泵型。ISWH泵多適用于化工、石油、造紙、制藥等領域故又被稱為化工離心泵、ISWH化工泵。上海速能生產的ISWH型不銹鋼離心泵耐腐蝕性能優越、運行可靠、使用壽命長、流道結構合理、如經酸洗加工外形美觀精致。
ISWH型離心泵可以根據客戶實際工況需要，自由選擇普通不銹鋼、不銹鋼304、不銹鋼316等等標號材質。
ISWH離心泵型號意義
ISWH65-160B
ISWH—不銹鋼臥式離心泵
65—進出口徑DN65（mm）
160—葉輪直徑（mm）
B— 葉輪經切削程度，B代表較多切削（型號尾部不帶英文字母的，即葉輪未經切削）
| 型號 | 進出口徑 | 流量 | 揚程 | 電機功率 | 電機轉速 | 效率 | 必需汽蝕余量 | |
|---|---|---|---|---|---|---|---|---|
| mm | m3/h | L/S | M | KW | r/min | % | （NPSH）r | |
| ISWH15-80 | 15 |
1.1 1.5 2.0 |
0.3 0.42 0.55 |
8.5 8 7 |
0.18 | 2800 |
26 34 34 |
2.3 |
| ISWH20-110 | 20 |
1.8 2.5 3.3 |
0.5 0.69 0.91 |
16 15 13.5 |
0.37 | 2800 |
25 34 35 |
2.3 |
| ISWH20-160 | 20 |
1.8 2.5 3.3 |
0.5 0.69 0.91 |
33 32 30 |
0.75 | 2900 |
19 25 23 |
2.3 |
| ISWH25-110 | 25 |
2.8 4 5.2 |
0.78 1.11 1.44 |
16 15 13.5 |
0.55 | 2900 |
34 42 41 |
2.3 |
| ISWH25-125 | 25 |
2.8 4 5.2 |
0.78 1.11 1.44 |
20.6 20 18 |
0.75 | 2900 |
28 36 35 |
2.3 |
| ISWH25-125A | 25 |
2.5 3.6 4.6 |
0.69 1.0 1.28 |
17 16 14.4 |
0.55 | 2900 | 35 | 2.3 |
| ISWH25-160 | 25 |
2.8 4 5.2 |
0.78 1.11 1.44 |
33 32 30 |
1.5 | 2900 |
24 32 33 |
2.3 |
| ISWH25-160A | 25 |
2.6 3.7 4.9 |
0.12 1.03 1.36 |
29 28 26 |
1.1 | 2900 | 31 | 2.3 |
| ISWH32-100(I) | 32 |
4.4 6.3 8.3 |
1.22 1.75 2.32 |
13.2 12.5 11.3 |
0.75 | 2900 |
48 54 53 |
2.0 |
| ISWH32-125 | 32 |
3.5 5 6.5 |
0.97 0.39 1.8 |
22 20 18 |
0.75 | 2900 |
40 44 42 |
2.3 |
| ISWH32-125A | 32 |
3.1 4.5 5.8 |
0.86 1.25 1.61 |
17.6 16 14.4 |
0.55 | 2900 | 43 | 2.3 |
| ISWH32-160(I) | 32 |
4.4 6.3 8.3 |
1.22 1.75 2.32 |
33.2 32 30.2 |
2.2 | 2900 |
34 40 42 |
2.0 |
| ISWH32-200(I) | 32 |
4.4 6.3 8.3 |
1.22 1.75 2.32 |
50.5 50 48 |
4 | 2900 |
26 33 35 |
2.0 |
| ISWH32-200A | 32 |
2.8 4 5.2 |
0.78 1.11 1.44 |
44.6 44 42.7 |
2.2 | 2900 |
34 40 42 |
2.0 |
| ISWH40-100 | 40 |
4.4 6.3 8.3 |
1.22 1.75 2.31 |
13.2 12.5 11.3 |
0.55 | 2900 |
48 54 53 |
2.3 |
| ISWH40-100A | 40 |
3.9 5.6 7.4 |
1.08 1.56 2.06 |
10.6 10 9 |
0.37 | 2900 | 52 | 2.3 |
| ISWH40-125 | 40 |
4.4 6.3 8.3 |
1.22 1.75 2.31 |
21 20 18 |
1.1 | 2900 |
41 46 43 |
2.3 |
| ISWH40-125A | 40 |
3.9 5.6 7.4 |
1.08 1.56 2.06 |
17.6 16 14.4 |
0.75 | 2900 |
40 45 41 |
2.3 |
| ISWH40-160 | 40 |
4.4 6.3 8.3 |
1.22 1.75 2.31 |
33 32 30 |
2.2 | 2900 |
35 40 40 |
2.3 |
| ISWH40-160A | 40 |
4.1 5.9 7.8 |
1.14 1.64 2.17 |
29 28 26.3 |
1.5 | 2900 |
34 39 39 |
2.3 |
| ISWH40-160B | 40 |
3.8 5.5 7.2 |
1.06 1.53 2.0 |
25.5 24 22.5 |
1.1 | 2900 |
34 38 37 |
2.3 |
| ISWH40-200 | 40 |
4.4 6.3 8.3 |
1.22 1.75 2.31 |
51 50 48 |
4 | 2900 |
26 33 32 |
2.3 |
| ISWH40-200A | 40 |
4.1 5.9 7.8 |
1.14 1.64 2.17 |
45 44 42 |
3 | 2900 |
26 31 30 |
2.3 |
| ISWH40-200B | 40 |
3.7 5.3 7.0 |
1.03 1.47 1.94 |
38 36 34.5 |
2.2 | 2900 | 29 | 2.3 |
| ISWH40-250 | 40 |
4.4 6.3 8.3 |
1.22 1.75 2.31 |
82 80 74 |
7.5 | 2900 |
24 28 28 |
2.3 |
| ISWH40-250A | 40 |
4.1 5.9 7.8 |
1.14 1.64 2.17 |
72 70 65 |
5.5 | 2900 |
24 28 27 |
2.3 |
| ISWH40-250B | 40 |
3.8 5.5 7.0 |
1.06 1.53 1.94 |
61.5 60 56 |
4 | 2900 |
23 27 26 |
2.3 |
| ISWH40-100(I) | 40 |
8.8 12.5 16.3 |
2.44 3.47 4.53 |
13.2 12.5 11.3 |
1.1 | 2900 |
55 62 60 |
2.3 |
| ISWH40-100(I)A | 40 |
8 11 14.5 |
2.22 3.05 4.03 |
10.6 10 9 |
0.75 | 2900 | 60 | 2.3 |
| ISWH40-125(I) | 40 |
8.8 12.5 16.3 |
2.44 3.47 4.53 |
21.2 20 17.8 |
1.5 | 2900 |
49 58 57 |
2.3 |
| ISWH40-125(I)A | 40 |
8 11 14.5 |
2.22 3.05 4.03 |
17 16 14 |
1.1 | 2900 | 57 | 2.3 |
| ISWH40-160(I) | 40 |
8.8 12.5 16.3 |
2.44 3.47 4.53 |
33 32 30 |
3 | 2900 |
45 52 51 |
2.3 |
| ISWH40-160(I)A | 40 |
8.2 11.7 15.2 |
2.28 3.25 4.22 |
29 28 26 |
2.2 | 2900 |
44 51 50 |
2.3 |
| ISWH40-160(I)B | 40 |
7.3 10.4 13.5 |
2.38 2.89 3.75 |
23 22 20.5 |
1.5 | 2900 | 50 | 2.3 |
| ISWH40-200(I) | 40 |
8.8 12.5 16.3 |
2.44 3.47 4.53 |
51.2 50 48 |
5.5 | 2900 |
38 46 46 |
2.3 |
| ISWH40-200(I)A | 40 |
8.3 11.7 15.3 |
2.31 3.25 4.25 |
45.0 44 42 |
4 | 2900 |
37 45 45 |
2.3 |
| ISWH40-200(I)B | 40 |
7.5 10.6 13.8 |
2.08 2.94 3.83 |
37 36 34 |
3 | 2900 | 44 | 2.3 |
| ISWH40-250(I) | 40 |
8.8 12.5 16.3 |
2.44 3.47 4.53 |
81.2 80 77.5 |
11 | 2900 |
31 38 40 |
2.3 |
| ISWH40-250(I)A | 40 |
8.2 11.6 15.2 |
2.28 3.22 4.22 |
71.0 70 68 |
7.5 | 2900 | 38 | 2.3 |
| ISWH40-250(I)B | 40 |
7.6 10.8 14 |
2.11 3.0 3.89 |
61.4 60 58 |
7.5 | 2900 | 37 | 2.3 |
| ISWH40-250(I)C | 40 |
7.1 10.0 13.1 |
1.97 2.78 3.64 |
53.2 52 50.4 |
5.5 | 2900 | 36 | 2.3 |
| ISWH50-100 | 50 |
8.8 12.5 16.3 |
2.44 3.47 4.53 |
13.6 12.5 11.3 |
1.1 | 2900 |
55 62 60 |
2.3 |
| ISWH50-100A | 50 |
8 11 14.5 |
2.22 3.05 4.03 |
11 10 9 |
0.75 | 2900 | 60 | 2.3 |
| ISWH50-125 | 50 |
8.8 12.5 16.3 |
2.44 3.47 4.53 |
21.5 20 17.8 |
1.5 | 2900 |
49 58 57 |
2.3 |
| ISWH50-125A | 50 |
8 11 14.5 |
2.22 3.05 4.03 |
17 16 14 |
1.1 | 2900 | 57 | 2.3 |
| ISWH50-160 | 50 |
8.8 12.5 16.3 |
2.44 3.47 4.53 |
33 32 30 |
3 | 2900 |
45 52 51 |
2.3 |
| ISWH50-160A | 50 |
8.2 11.7 15.2 |
2.28 3.25 4.22 |
29 28 26 |
2.2 | 2900 |
44 51 50 |
2.3 |
| ISWH50-160B | 50 |
7.3 10.4 13.5 |
2.38 2.89 3.75 |
23 22 20.5 |
1.5 | 2900 | 50 | 2.3 |
| ISWH50-200 | 50 |
8.8 12.5 16.3 |
2.44 3.47 4.53 |
52 50 48 |
5.5 | 2900 |
38 46 46 |
2.3 |
| ISWH50-200A | 50 |
8.3 11.7 15.3 |
2.31 3.25 4.25 |
45.8 44 42 |
4 | 2900 |
37 45 45 |
2.3 |
| ISWH50-200B | 50 |
7.5 10.6 13.8 |
2.08 2.94 3.83 |
37 36 34 |
3 | 2900 | 44 | 2.3 |
| ISWH50-250 | 50 |
8.8 12.5 16.3 |
2.44 3.47 4.53 |
82 80 77.5 |
11 | 2900 |
29 38 40 |
2.3 |
| ISWH50-250A | 50 |
8.2 11.6 15.2 |
2.28 3.22 4.22 |
71.5 70 68 |
7.5 | 2900 | 38 | 2.3 |
| ISWH50-250B | 50 |
7.6 10.8 14 |
2.11 3.0 3.89 |
61.4 60 58 |
7.5 | 2900 | 37 | 2.3 |
| ISWH50-250C | 50 |
7.1 10.0 13.1 |
1.97 2.78 3.64 |
53.2 52 50.4 |
5.5 | 2900 | 36 | 2.3 |
| ISWH50-100(I) | 50 |
17.5 25 32.5 |
4.86 6.94 9.03 |
13.7 12.5 10.5 |
1.5 | 2900 |
67 69 69 |
2.5 |
| ISWH50-100(I)A | 50 |
15.6 22.3 29 |
4.3 6.19 8.1 |
11 10 8.4 |
1.1 | 2900 |
65 67 68 |
2.5 |
| ISWH50-125(I) | 50 |
17.5 25 32.5 |
4.86 6.94 9.03 |
21.5 20 18 |
3 | 2900 |
60 68 67 |
2.5 |
| ISWH50-125(I)A | 50 |
15.6 22.3 29 |
4.33 6.19 8.1 |
17 16 13.6 |
2.2 | 2900 |
58 66 65 |
2.5 |
| ISWH50-160(I) | 50 |
17.5 25 32.5 |
4.68 6.94 9.03 |
34.4 32 27.5 |
4 | 2900 |
54 63 60 |
2.5 |
| ISWH50-160(I)A | 50 |
16.4 23.4 30.4 |
4.56 6.5 8.44 |
30 28 24 |
4 | 2900 |
54 62 59 |
2.5 |
| ISWH50-160(I)B | 50 |
15.0 21.6 28 |
4.17 6.0 7.78 |
26 24 20.6 |
3 | 2900 | 58 | 2.5 |
| ISWH50-200(I) | 50 |
17.5 25 32.5 |
4.86 6.94 9.03 |
52.7 50 45.5 |
7.5 | 2900 |
49 58 59 |
2.5 |
| ISWH50-200(I)A | 50 |
16.4 23.5 30.5 |
4.56 6.53 8.47 |
46.4 44 40 |
7.5 | 2900 |
48 57 58 |
2.5 |
| ISWH50-200(I)B | 50 |
15.2 21.8 28.3 |
4.22 6.06 7.86 |
40 38 34.5 |
5.5 | 2900 | 55 | 2.5 |
| ISWH50-250(I) | 50 |
17.5 25 32.5 |
4.86 6.94 9.03 |
82 80 76.5 |
15 | 2900 |
39 50 52 |
2.5 |
| ISWH50-250(I)A | 50 |
16.4 23.4 30.5 |
4.56 6.5 8.47 |
71.5 70 67 |
11 | 2900 |
39 50 52 |
2.5 |
| ISWH50-250(I)B | 50 |
15 21.6 28 |
4.17 6.0 7.78 |
61 60 57.4 |
11 | 2900 |
38 49 54 |
2.5 |
| ISWH50-315(I) | 50 |
17.5 25 32.5 |
4.86 6.94 9.03 |
128 125 122 |
30 | 2900 |
30 40 44 |
2.5 |
| ISWH50-315(I)A | 50 |
16.6 23.7 31 |
4.61 6.58 8.6 |
115 113 110 |
22 | 2900 |
30 40 44 |
2.5 |
| ISWH50-315(I)B | 50 |
15.7 22.5 29.2 |
4.36 6.25 8.0 |
103 101 98 |
18.5 | 2900 | 39 | 2.5 |
| ISWH50-315(I)C | 50 |
14.4 20.6 26.8 |
4.0 5.72 7.44 |
86 85 83 |
15 | 2900 | 38 | 2.5 |
| ISWH65-100 | 65 |
17.5 25 32.5 |
4.86 6.94 9.03 |
13.7 12.5 10.5 |
1.5 | 2900 |
67 69 69 |
2.5 |
| ISWH65-100A | 65 |
15.6 22.3 29 |
4.3 6.19 8.1 |
11 10 8.4 |
1.1 | 2900 |
65 67 68 |
2.5 |
| ISWH65-125 | 65 |
17.5 25 32.5 |
4.86 6.94 9.03 |
21.5 20 18 |
3 | 2900 |
60 68 67 |
2.5 |
| ISWH65-125A | 65 |
15.6 22.3 29 |
4.33 6.19 8.1 |
17 16 14.4 |
2.2 | 2900 |
58 66 65 |
2.5 |
| ISWH65-160 | 65 |
17.5 25 32.5 |
4.86 6.94 9.03 |
34.4 32 27.5 |
4 | 2900 |
54 63 60 |
2.5 |
| ISWH65-160A | 65 |
16.4 23.4 30.4 |
4.56 6.5 8.44 |
30 28 24 |
4 | 2900 |
54 62 59 |
2.5 |
| ISWH65-160B | 65 |
15.0 21.6 28 |
4.17 6.0 7.78 |
26 24 20.6 |
3 | 2900 | 58 | 2.5 |
| ISWH65-200 | 65 |
17.5 25 32.5 |
4.86 6.94 9.03 |
52.7 50 45.5 |
7.5 | 2900 |
49 58 59 |
2.5 |
| ISWH65-200A | 65 |
16.4 23.5 30.5 |
4.56 6.53 8.47 |
46.4 44 40 |
7.5 | 2900 |
48 57 58 |
2.5 |
| ISWH65-200B | 65 |
15.2 21.8 28.3 |
4.22 6.06 7.86 |
40 38 34.5 |
5.5 | 2900 | 55 | 2.5 |
| ISWH65-250 | 65 |
17.5 25 32.5 |
4.86 6.94 9.03 |
82 80 76.5 |
15 | 2900 |
39 50 52 |
2.5 |
| ISWH65-250A | 65 |
16.4 23.4 30.5 |
4.56 6.5 8.47 |
71.5 70 67 |
11 | 2900 |
39 50 52 |
2.5 |
| ISWH65-250B | 65 |
15 21.6 28 |
4.17 6.0 7.78 |
61 60 57.4 |
11 | 2900 |
38 49 54 |
2.5 |
| ISWH65-315 | 65 |
17.5 25 32.5 |
4.86 6.94 9.03 |
127 125 122 |
30 | 2900 |
32 40 44 |
2.5 |
| ISWH65-315A | 65 |
16.6 23.7 31 |
4.61 6.58 8.6 |
115 113 110 |
22 | 2900 |
32 40 44 |
2.5 |
| ISWH65-315B | 65 |
15.7 22.5 29.2 |
4.36 6.25 8.0 |
103 101 98 |
18.5 | 2900 | 39 | 2.5 |
| ISWH65-315C | 65 |
14.4 20.6 26.8 |
4.0 5.72 7.44 |
86 85 83 |
15 | 2900 | 38 | 2.5 |
| ISWH65-100(I) | 65 |
35 50 65 |
9.72 13.9 18.1 |
13.8 12.5 10 |
3 | 2900 |
67 73 70 |
3.0 |
| ISWH65-100(I)A | 65 |
31.3 44.7 58 |
8.7 12.4 16.1 |
11 10 8 |
2.2 | 2900 |
66 72 69 |
3.0 |
| ISWH65-125(I) | 65 |
35 50 65 |
9.72 13.9 18.1 |
22 20 17 |
5.5 | 2900 |
67 72.5 70 |
3.0 |
| ISWH65-125(I)A | 65 |
31.3 44.7 58 |
8.7 12.5 16.1 |
17.5 16 13.6 |
4 | 2900 |
66 71 69 |
3.0 |
| ISWH65-160(I) | 65 |
35 50 65 |
9.72 13.9 18.1 |
35 32 28 |
7.5 | 2900 |
63 71 70 |
3.0 |
| ISWH65-160(I)A | 65 |
32.7 46.7 61 |
9.1 13.0 16.9 |
30.6 28 24 |
7.5 | 2900 |
62 70 69 |
3.0 |
| ISWH65-160(I)B | 65 |
30.3 43.3 56.3 |
8.4 12.0 15.6 |
26 24 21 |
5.5 | 2900 | 69 | 3.0 |
| ISWH65-200(I) | 65 |
35 50 65 |
9.72 13.9 18.1 |
53.5 50 46 |
15 | 2900 |
55 67 68 |
3.0 |
| ISWH65-200(I)A | 65 |
32.8 47 61 |
9.1 13.1 16.9 |
47 44 40 |
11 | 2900 |
54 66 67 |
3.0 |
| ISWH65-200(I)B | 65 |
30.5 43.5 56.6 |
8.5 12.1 15.7 |
40.6 38 33.4 |
7.5 | 2900 | 65 | 3.0 |
| ISWH65-250(I) | 65 |
35 50 65 |
9.72 13.9 18.1 |
83 80 72 |
22 | 2900 |
52 59 60 |
3.0 |
| ISWH65-250(I)A | 65 |
32.5 46.7 61 |
9.0 13.0 16.9 |
73 70 63 |
18.5 | 2900 |
52 59 60 |
3.0 |
| ISWH65-250(I)B | 65 |
30 43.3 56 |
8.3 12.0 15.6 |
62 60 54 |
15 | 2900 | 58 | 3.0 |
| ISWH65-315(I) | 65 |
35 50 65 |
9.72 13.9 18.1 |
128 125 121 |
37 | 2900 |
44 54 57 |
3.0 |
| ISWH65-315(I)A | 65 |
32.5 46.5 60.5 |
9.0 12.9 16.8 |
112.6 110 106.4 |
30 | 2900 |
43 54 57 |
3.0 |
| ISWH65-315(I)B | 65 |
31 44.5 58 |
8.6 12.4 16.1 |
102.5 100 98 |
30 | 2900 | 53 | 3.0 |
| ISWH65-315(I)C | 65 |
29 41 53.6 |
8.1 11.4 14.9 |
87 85 83 |
22 | 2900 | 51 | 3.0 |
| ISWH80-100 | 80 |
35 50 65 |
9.72 13.9 18.1 |
13.8 12.5 10 |
3 | 2900 |
67 73 70 |
3.0 |
| ISWH80-100A | 80 |
31.3 44.7 58 |
8.7 12.5 16.1 |
11 10 8 |
2.2 | 2900 |
66 72 69 |
3.0 |
| ISWH80-125 | 80 |
35 50 65 |
9.72 13.9 18.1 |
22 20 17 |
5.5 | 2900 |
67 72.5 70 |
3.0 |
| ISWH80-125A | 80 |
31.3 45 58 |
8.7 12.5 16.1 |
17.5 16 13.6 |
4 | 2900 |
66 71 69 |
3.0 |
| ISWH80-160 | 80 |
35 50 65 |
9.72 13.9 18.1 |
35 32 28 |
7.5 | 2900 |
63 71 70 |
3.0 |
| ISWH80-160A | 80 |
32.7 46.7 61 |
9.1 13.0 16.9 |
30.6 28 24 |
7.5 | 2900 |
62 70 69 |
3.0 |
| ISWH80-160B | 80 |
30.3 43.3 56.3 |
8.4 12.0 15.6 |
26 24 21 |
5.5 | 2900 | 69 | 3.0 |
| ISWH80-200 | 80 |
35 50 65 |
9.72 13.9 18.1 |
53.5 50 46 |
15 | 2900 |
55 67 68 |
3.0 |
| ISWH80-200A | 80 |
32.8 47 61 |
9.1 13.1 16.9 |
47 44 40 |
11 | 2900 |
54 66 67 |
3.0 |
| ISWH80-200B | 80 |
30.5 43.5 56.6 |
8.5 12.1 15.7 |
40.6 38 33.4 |
7.5 | 2900 | 65 | 3.0 |
| ISWH80-250 | 80 |
35 50 65 |
9.72 13.9 18.1 |
83 80 72 |
22 | 2900 |
52 59 60 |
3.0 |
| ISWH80-250A | 80 |
32.5 46.7 61 |
9.0 13.0 16.9 |
73 70 63 |
18.5 | 2900 |
52 59 60 |
3.0 |
| ISWH80-250B | 80 |
30 43.3 56 |
8.3 12.0 15.6 |
62 60 54 |
15 | 2900 | 58 | 3.0 |
| ISWH80-315 | 80 |
35 50 65 |
9.72 13.9 18.1 |
128 125 122 |
37 | 2900 |
43 54 57 |
3.0 |
| ISWH80-315A | 80 |
32.5 46.5 60.5 |
9.0 12.9 16.8 |
112.6 110 107.4 |
30 | 2900 |
43 54 57 |
3.0 |
| ISWH80-315B | 80 |
31 44.5 58 |
8.6 12.4 16.1 |
102.5 100 98 |
30 | 2900 | 53 | 3.0 |
| ISWH80-315C | 80 |
29 41 53.6 |
8.1 11.4 14.9 |
98 85 83 |
22 | 2900 | 51 | 3.0 |
| ISWH80-350 | 80 |
35 50 65 |
9.72 13.9 18.1 |
146 150 142 |
55 | 2900 |
55 66 67 |
3.0 |
| ISWH80-350A | 80 |
31 44.5 58 |
8.6 12.4 16.1 |
138.4 142 134.8 |
45 | 2900 | 65 | 3.0 |
| ISWH80-350B | 80 |
29 41 53.6 |
8.1 11.4 14.9 |
131.4 135 127.8 |
37 | 2900 | 63 | 3.0 |
| ISWH80-100(I) | 80 |
70 100 130 |
19.4 27.8 36.1 |
13.6 12.5 11 |
5.5 | 2900 |
66 76 75 |
4.5 |
| ISWH80-100(I)A | 80 |
62.6 89 116 |
17.4 24.7 32.2 |
11 10 8.8 |
4 | 2900 |
64 74 74 |
4.5 |
| ISWH80-125(I) | 80 |
70 100 130 |
19.4 27.8 36.1 |
23.5 20 14 |
11 | 2900 |
70 76 65 |
4.5 |
| ISWH80-125(I)A | 80 |
62.6 89 116 |
17.4 24.7 32.2 |
19 16 11 |
7.5 | 2900 |
68 74 65 |
4.5 |
| ISWH80-160(I) | 80 |
70 100 130 |
19.4 27.8 36.1 |
36.5 32 24 |
15 | 2900 |
70 76 65 |
4.5 |
| ISWH80-160(I)A | 80 |
65.4 93.5 121.6 |
18.2 26.0 33.8 |
32 28 21 |
11 | 2900 |
68 74 67 |
4.5 |
| ISWH80-160(I)B | 80 |
60.6 86.6 112.5 |
16.8 24.1 31.3 |
72 24 18 |
11 | 2900 | 72 | 4.5 |
| ISWH80-200(I) | 80 |
70 100 130 |
19.4 27.8 36.1 |
54 50 42 |
22 | 2900 |
65 74 73 |
4.0 |
| ISWH80-200(I)A | 80 |
65.4 93.5 121.6 |
18.2 26.0 33.8 |
47.5 44 37 |
18.5 | 2900 |
64 73 72 |
4.0 |
| ISWH80-200(I)B | 80 |
61 87 113 |
16.9 24.2 31.4 |
41 38 32 |
15 | 2900 | 71 | 4.0 |
| ISWH80-250(I) | 80 |
70 100 130 |
19.4 27.8 36.1 |
87 80 68 |
37 | 2900 |
62 69 68 |
4.0 |
| ISWH80-250(I)A | 80 |
65.4 93.5 121.6 |
18.2 26.0 33.8 |
76 70 59.5 |
30 | 2900 |
61 68 67 |
4.0 |
| ISWH80-250(I)B | 80 |
61 87 113 |
16.9 24.2 31.4 |
65 60 51 |
30 | 2900 | 66 | 4.0 |
| ISWH80-315(I) | 80 |
70 100 130 |
19.4 27.8 36.1 |
132 125 114 |
75 | 2900 |
55 66 67 |
4.0 |
| ISWH80-315(I)A | 80 |
66.5 95 123.6 |
18.5 26.4 34.3 |
119 113 103 |
55 | 2900 |
55 66 67 |
4.0 |
| ISWH80-315(I)B | 80 |
63 90 117 |
17.5 25 32.5 |
106.6 101 92 |
45 | 2900 | 65 | 4.0 |
| ISWH80-315(I)C | 80 |
58 82 107 |
16.1 22.8 29.7 |
90 85 76 |
37 | 2900 | 63 | 4.0 |
| ISWH100-100 | 100 |
70 100 130 |
19.4 27.8 36.1 |
13.6 12.5 11 |
5.5 | 2900 |
66 76 75 |
4.5 |
| ISWH100-100A | 100 |
62.6 89 116 |
17.4 47 32.2 |
11 10 8.8 |
4 | 2900 |
64 74 74 |
4.5 |
| ISWH100-125 | 100 |
70 100 130 |
19.4 27.8 36.1 |
23.5 20 14 |
11 | 2900 |
70 76 65 |
4.5 |
| ISWH100-125A | 100 |
62.6 89 116 |
17.4 24.7 32.2 |
19 16 11 |
7.5 | 2900 |
68 74 63 |
4.5 |
| ISWH100-160 | 100 |
70 100 130 |
19.4 27.8 36.1 |
36.5 32 24 |
15 | 2900 |
70 76 65 |
4.5 |
| ISWH100-160A | 100 |
65.4 93.5 121.6 |
18.2 26.0 33.8 |
32 28 21 |
11 | 2900 |
68 74 67 |
4.5 |
| ISWH100-160B | 100 |
60.6 86.6 112.5 |
16.8 24.1 31.3 |
27 24 18 |
11 | 2900 | 72 | 4.5 |
| ISWH100-200 | 100 |
70 100 130 |
19.4 27.8 36.1 |
54 50 42 |
22 | 2900 |
65 74 73 |
4.0 |
| ISWH100-200A | 100 |
65.4 93.5 121.6 |
18.2 26.0 33.8 |
47.5 44 37 |
18.5 | 2900 |
64 73 72 |
4.0 |
| ISWH100-200B | 100 |
61 87 113 |
16.9 24.2 31.4 |
41 38 32 |
15 | 2900 | 71 | 4.0 |
| ISWH100-250 | 100 |
70 100 130 |
19.4 27.8 36.1 |
37 80 68 |
37 | 2900 |
62 69 68 |
4.0 |
| ISWH100-250A | 100 |
65.4 93.5 121.6 |
18.2 26.0 33.8 |
76 70 59.5 |
30 | 2900 |
61 68 67 |
4.0 |
| ISWH100-250B | 100 |
61 87 113 |
16.9 24.2 31.4 |
65 60 51 |
30 | 2900 | 66 | 4.0 |
| ISWH100-315 | 100 |
70 100 130 |
19.4 27.8 36.1 |
132 125 114 |
75 | 2900 |
55 66 67 |
4.0 |
| ISWH100-315A | 100 |
66.5 95 123.6 |
18.5 26.4 34.3 |
119 113 103 |
55 | 2900 |
65 66 67 |
4.0 |
| ISWH100-315B | 100 |
63 90 117 |
17.5 25 32.5 |
106.6 101 92 |
45 | 2900 | 65 | 4.0 |
| ISWH100-315C | 100 |
58 82 107 |
16.1 22.8 29.7 |
90 85 76 |
37 | 2900 | 63 | 4.0 |
| ISWH100-100(I) | 100 |
96 160 192 |
26.7 44.4 53.3 |
14 12.5 10 |
11 | 2900 |
64 73 70 |
4.5 |
| ISWH100-125(I) | 100 |
96 160 192 |
26.7 44.4 53.3 |
24 20 14 |
15 | 2900 |
62 74 69 |
4.5 |
| ISWH100-125(I)A | 100 |
84 140 168 |
23.3 39 46.7 |
20 17 12 |
11 | 2900 |
64 72 68 |
4.5 |
| ISWH100-160(I) | 100 |
96 160 192 |
26.7 44.4 53.3 |
36 32 27 |
22 | 2900 |
69 79 75 |
5.6 |
| ISWH100-160(I)A | 100 |
84 140 168 |
23.3 39 46.7 |
32 28 23.5 |
18.5 | 2900 |
66 76 72 |
5.0 |
| ISWH100-200(I) | 100 |
96 160 192 |
26.7 44.4 53.3 |
53 50 45 |
37 | 2900 |
69 79 78 |
5.2 |
| ISWH100-200(I)A | 100 |
84 140 168 |
23.3 39 46.7 |
48 45 40 |
30 | 2900 |
64 74 73 |
4.5 |
| ISWH100-200(I)B | 100 |
60 100 120 |
16.7 27.8 33.3 |
43 40 36 |
22 | 2900 | 72 | 4.5 |
| ISWH100-250(I) | 100 |
96 160 192 |
26.7 44.4 53.3 |
83 80 72 |
55 | 2900 |
65 77 74 |
4.8 |
| ISWH100-250(I)A | 100 |
84 140 168 |
23.3 39 46.7 |
75 72 65 |
45 | 2900 |
60 72 69 |
4.5 |
| ISWH100-250(I)B | 100 |
60 100 120 |
16.7 27.8 33.3 |
68 65 58 |
37 | 2900 | 70 | 4.5 |
| ISWH100-350 | 100 |
60 100 120 |
16.7 27.8 33.3 |
153.6 150 142 |
90 | 2900 |
72 57 74 |
4.0 |
| ISWH100-350A | 100 |
61 87 113 |
16.9 24.2 31.4 |
145.6 142 134 |
75 | 2900 | 75 | 4.0 |
| ISWH100-350B | 100 |
58 82 107 |
16.1 22.8 29.7 |
138.6 135 127 |
55 | 2900 | 75 | 4.0 |
| ISWH125-100 | 125 |
96 160 192 |
26.7 44.4 53.3 |
13 12.5 12 |
11 | 2900 | 82 | 4.0 |
| ISWH125-100A | 125 |
86 143 172 |
23.9 39.7 47.8 |
10.4 10 9.6 |
7.5 | 2900 | 77 | 4.0 |
| ISWH125-125 | 125 |
96 160 192 |
26.7 44.4 53.3 |
22.6 20 17 |
15 | 2900 | 80 | 4.0 |
| ISWH125-125A | 125 |
86 143 172 |
23.9 39.7 47.8 |
18 16 13.6 |
11 | 2900 | 77 | 4.0 |
| ISWH125-160 | 125 |
96 160 192 |
26.7 44.4 53.3 |
36 32 28 |
22 | 2900 | 78 | 4.0 |
| ISWH125-160A | 125 |
90 150 180 |
25 41.7 50 |
31.5 28 24.5 |
18.5 | 2900 | 76 | 4.0 |
| ISWH125-160B | 125 |
83 138 166 |
21.7 38.3 46.1 |
27 24 21 |
15 | 2900 | 73 | 4.0 |
| ISWH125-200 | 125 |
96 160 192 |
26.7 44.4 53.3 |
55 50 46 |
37 | 2900 | 77 | 5.5 |
| ISWH125-200A | 125 |
90 150 180 |
25 41.7 50 |
48.4 44 40.5 |
30 | 2900 | 76 | 5.5 |
| ISWH125-200B | 125 |
83 138 166 |
21.7 38.3 46.1 |
41.3 37.5 34.5 |
22 | 2900 | 75 | 5.5 |
| ISWH125-250 | 125 |
96 160 192 |
26.7 44.4 53.3 |
87 80 73 |
55 | 2900 | 75 | 5.0 |
| ISWH125-250A | 125 |
90 150 180 |
25 41.7 50 |
76 70 84 |
45 | 2900 | 74 | 5.5 |
| ISWH125-250B | 125 |
83 138 166 |
21.7 38.3 46.1 |
65 60 55 |
37 | 2900 | 73 | 5.5 |
| ISWH125-315 | 125 |
96 160 192 |
26.7 44.7 53.3 |
133 125 119 |
90 | 2900 | 70 | 5.0 |
| ISWH125-315A | 125 |
90 150 180 |
25 41.7 50 |
117 110 104.6 |
75 | 2900 | 70 | 5.0 |
| ISWH125-315B | 125 |
86 143 172 |
23.9 39.7 47.8 |
106.4 100 95.2 |
75 | 2900 | 69 | 5.0 |
| ISWH125-315C | 125 |
80.5 134 161 |
22.4 37.2 44.7 |
96 88 86 |
55 | 2900 | 67 | 5.0 |
| ISWH150-125 | 150 |
96 160 192 |
26.7 44.4 53.3 |
22.6 24 17 |
11 | 2900 |
66 76 76 |
4.0 |
| ISWH150-125A | 150 |
90 150 180 |
25 41.7 50 |
18 16 13.6 |
7.5 | 2900 | 77 | 4.0 |
| ISWH150-160 | 150 |
96 160 192 |
26.7 44.4 53.3 |
36 32 27 |
22 | 2900 | 75 | 4.0 |
| ISWH150-160A | 150 |
90 150 180 |
25 41.7 50 |
32 28 23.5 |
18.5 | 2900 | 76 | 4.0 |
| ISWH150-160B | 150 |
84 140 168 |
23.3 39 46.7 |
27 24 21 |
15 | 2900 | 73 | 4.0 |
| ISWH150-200 | 150 |
140 200 260 |
38.9 55.6 72.2 |
13.8 12.5 10.6 |
15 | 1450 |
68 78 78 |
3.0 |
| ISWH150-200A | 150 |
125 176 232.5 |
34.7 49.7 64.6 |
11 10 8.5 |
11 | 1450 |
66 76 76 |
3.0 |
| ISWH150-200B | 150 |
84 140 168 |
23.3 39 46.7 |
41 38 34 |
22 | 2900 | 75 | 4.0 |
| ISWH150-250 | 150 |
140 200 260 |
38.9 55.6 72.2 |
21.8 20 17 |
18.5 | 1450 |
73 79 77 |
3.0 |
| ISWH 50-250A | 150 |
129 184.4 240 |
35.8 51.2 66.7 |
18.5 17 14.4 |
15 | 1450 |
72 78 76 |
3.0 |
| ISWH 50-250B | 150 |
117 167 217.5 |
32.5 46.4 60.4 |
15.2 14 12 |
11 | 1450 | 76 | 3.0 |
| ISWH150-315 | 150 |
140 200 260 |
38.9 55.6 72.2 |
33.8 32 28 |
30 | 1450 |
70 78 73 |
2.5 |
| ISWH150-315A | 150 |
131 187 243 |
36.4 51.9 67.5 |
29.5 28 24.5 |
22 | 1450 |
69 77 77 |
3.5 |
| ISWH150-315B | 150 |
121 173 225 |
33.5 48.1 62.5 |
25 24 21 |
18.5 | 1450 | 76 | 3.5 |
| ISWH150-350 | 150 |
96 160 192 |
26.7 44.4 53.3 |
153.6 150 142.8 |
110 | 2900 | 80 | 5.5 |
| ISWH150-350A | 150 |
90 150 180 |
25 41.7 50 |
145.6 142 134.8 |
90 | 2900 | 70 | 5.2 |
| ISWH150-350B | 150 |
84 140 168 |
23.3 39 46.7 |
138.6 135 127.8 |
75 | 2900 |
65 76 74 |
5.5 |
| ISWH150-400 | 150 |
140 200 260 |
38.9 55.6 72.2 |
53 50 44 |
45 | 1450 |
68 75 71 |
3.5 |
| ISWH150-400A | 150 |
131 187 243 |
36.4 51.9 67.5 |
46.6 44 38.3 |
37 | 1450 |
67 74 70 |
3.5 |
| ISWH150-400B | 150 |
122 174 226.5 |
33.9 48.3 62.9 |
40 38 33 |
30 | 1450 | 73 | 3.5 |
| ISWH150-400C | 150 |
112 160 208 |
31.1 44.4 57.8 |
34 32 28 |
22 | 1450 | 71 | 3.5 |
| ISWH150-250(I) | 150 |
120 200 240 |
33.3 55.6 66.7 |
87 80 72 |
75 | 2900 |
65 76 74 |
4.5 |
| ISWH150-250(I)A | 150 |
112 187 224 |
31.1 51.9 62.2 |
76 70 63 |
55 | 2900 |
64 75 73 |
4.5 |
| ISWH150-250(I)B | 150 |
104 173 208 |
28.9 48.1 57.8 |
65 60 54 |
45 | 2900 |
63 74 72 |
4.5 |
| ISWH150-315(I) | 150 |
120 200 240 |
33.3 55.6 66.7 |
133 125 120 |
110 | 2900 |
58 73 75 |
4.5 |
| ISWH150-315(I)A | 150 |
112 187 224 |
31.1 51.9 62.2 |
116 110 105 |
90 | 2900 |
57 72 74 |
4.5 |
| ISWH150-315(I)B | 150 |
104 173 208 |
28.9 48.1 57.8 |
100 95 91 |
75 | 2900 |
55 70 72 |
4.5 |
| ISWH200-200 | 200 |
140 200 260 |
38.9 55.6 72.2 |
13.8 12.5 10.6 |
15 | 1450 |
68 78 78 |
3.0 |
| ISWH200-200A | 200 |
125 179 232.5 |
34.7 49.7 64.6 |
11 10 8.5 |
11 | 1450 |
66 76 76 |
3.0 |
| ISWH200-250 | 200 |
140 200 260 |
21.8 20 17 |
21.8 20 17 |
18.5 | 1450 |
73 79 77 |
3.0 |
| ISWH200-250A | 200 |
129 184.4 240 |
18.5 17 14.4 |
18.5 17 14.4 |
15 | 1450 |
72 78 76 |
3.0 |
| ISWH200-250B | 200 |
117 167 217.5 |
15.2 14 12 |
15.2 14 12 |
11 | 1450 | 76 | 3.0 |
| ISWH200-315 | 200 |
140 200 260 |
33.8 32 28 |
33.8 32 28 |
30 | 1450 |
70 78 78 |
3.5 |
| ISWH200-315A | 200 |
131 189 243 |
29.5 28 24.5 |
29.5 28 24.5 |
22 | 1450 |
69 77 77 |
3.5 |
| ISWH200-315B | 200 |
121 173 225 |
25 24 21 |
25 24 21 |
18.5 | 1450 | 76 | 3.5 |
| ISWH200-400 | 200 |
140 200 260 |
53 50 44 |
53 50 44 |
45 | 1450 |
68 75 71 |
3.5 |
| ISWH200-400A | 200 |
131 187 243 |
46.6 44 38.3 |
46.6 44 38.3 |
37 | 1450 |
67 74 70 |
3.5 |
| ISWH200-400B | 200 |
122 174 226.5 |
40 38 33 |
40 38 33 |
30 | 1450 | 73 | 3.5 |
| ISWH200-400C | 200 |
112 160 208 |
34 32 28 |
34 32 28 |
22 | 1450 | 71 | 3.5 |
| ISWH200-200(I) | 200 |
280 400 520 |
77.8 111.1 144 |
13.4 12.5 10.5 |
22 | 1450 |
70 80 79 |
4.0 |
| ISWH200-200(I)A | 200 |
250 358 465 |
69.4 90.4 129.2 |
10.7 10 8.5 |
18.5 | 1450 |
68 73 77 |
4.0 |
| ISWH200-250(I) | 200 |
280 400 520 |
77.8 111.1 144 |
22.2 20 14 |
30 | 1450 |
75 80 72 |
4.0 |
| ISWH200-250(I)A | 200 |
250 358 465 |
69.4 99.4 129.2 |
18 16 11.2 |
22 | 1450 |
73 78 70 |
4.0 |
| ISWH200-250(I)B | 200 |
226 322 419 |
62.8 89.4 116.4 |
14.4 13 7.3 |
18.5 | 1450 |
70 75 67 |
4.0 |
| ISWH200-315(I) | 200 |
280 400 520 |
77.8 111.4 144 |
36 32 26 |
55 | 1450 |
73 80 75 |
4.0 |
| ISWH200-315(I)A | 200 |
262 374 486 |
72.8 103.9 135 |
31.5 28 23 |
45 | 1450 |
72 79 74 |
4.0 |
| ISWH200-315(I)B | 200 |
242 346 450 |
67.3 96.1 125 |
27 24 19.5 |
37 | 1450 | 78 | 4.0 |
| ISWH200-400(I) | 200 |
280 400 520 |
77.8 111.4 144 |
54.5 50 39 |
75 | 1450 |
75 81 77 |
4.0 |
| ISWH200-400(I)A | 200 |
262 374 486 |
72.8 103.9 135 |
48 44 34 |
75 | 1450 | 80 | 4.0 |
| ISWH200-400(I)B | 200 |
242 346 450 |
67.2 96.1 125 |
41.4 38 29.6 |
55 | 1450 | 78 | 5.0 |
| ISWH200-400(I)C | 200 |
224 320 416 |
62.2 88.9 115.6 |
34.9 32 25 |
45 | 1450 | 76 | 5.0 |
| ISWH250-250 | 250 |
350 550 650 |
97.2 152.8 180.5 |
22 20 16 |
45 | 1450 |
78 82 81 |
5.0 |
| ISWH250-250A | 250 |
300 500 600 |
83.3 139 166.7 |
18.3 17 14 |
37 | 1450 |
76 80 80 |
5.0 |
| ISWH250-235 | 250 |
300 500 600 |
83.3 139 166.7 |
14 12.5 11 |
22 | 1480 |
73 78 70 |
4.5 |
| ISWH250-300 | 250 |
300 500 600 |
83.3 139 166.7 |
22 20 16 |
37 | 1480 | 78 | 4.5 |
| ISWH250-315 | 250 |
350 550 650 |
97.2 152.8 180.5 |
34 32 28 |
75 | 1450 |
76 80 79 |
5.5 |
| ISWH250-315A | 250 |
300 500 600 |
83.3 139 166.7 |
29.5 28 24 |
55 | 1450 |
74 78 77 |
5.5 |
| ISWH250-315B | 250 |
260 450 520 |
72.2 125 144.4 |
25 24 20 |
45 | 1450 |
70 74 72 |
5.5 |
| ISWH250-400 | 250 |
300 500 600 |
83.3 139 166.7 |
54.5 50 39 |
90 | 1480 | 72 | 4.5 |
| ISWH300-235 | 300 |
480 720 900 |
133.3 200 250 |
20 18 15.5 |
55 | 970 |
77 81 74 |
5.0 |
| ISWH300-235A | 300 |
438 607 821 |
121.7 182.5 228.1 |
16.5 15 13 |
45 | 970 |
75 79 72 |
5.0 |
| ISWH300-235B | 300 |
400 600 750 |
111.1 167.0 208.3 |
14 12.5 11 |
37 | 970 |
73 77 70 |
5.0 |
| ISWH300-300 | 300 |
480 720 900 |
133.3 200 250 |
31 28 25 |
75 | 970 |
77 81 77 |
5.0 |
| ISWH300-300A | 300 |
444 666 833 |
123.3 185 231.4 |
26.5 24 21.5 |
75 | 970 |
76 80 76 |
5.0 |
| ISWH300-300B | 300 |
415 623 779 |
115.3 173.1 261.4 |
23 21 18.5 |
55 | 970 | 79 | 5.0 |
| ISWH300-380 | 300 |
480 720 900 |
133.3 200 250 |
48 44 34 |
132 | 970 | 84 | 5.0 |
| ISWH300-380A | 300 |
444 666 833 |
123.3 185 231.4 |
41.4 38 30 |
110 | 970 | 80 | 5.0 |
| ISWH300-380B | 300 |
409 614 767 |
113.6 170.6 213.1 |
35 32 25 |
90 | 970 | 78 | 5.0 |
| ISWH300-235(I) | 300 |
718 1080 1345 |
199.4 300 373.6 |
44.6 40 34.6 |
160 | 1450 | 82 | 5.5 |
| ISWH300-235(I)A | 300 |
642 965 1203 |
178.3 268.1 334.2 |
35.7 32 27.7 |
132 | 1450 | 80 | 5.5 |
| ISWH300-390 | 300 |
540 720 900 |
150 200 250 |
20.5 18 15.5 |
55 | 980 |
78 81 76 |
|
| ISWH300-390A | 300 |
450 600 720 |
126 167 200 |
17.2 15 12.8 |
45 | 980 |
77 79 75 |
|
| ISWHISWH300-390B | 300 |
400 540 650 |
111 150 180 |
14 12.5 11.5 |
37 | 980 |
74 77 76 |
|
| ISWH300-400 | 300 |
450 600 720 |
125 166 200 |
55 50 42.5 |
110 | 1480 | 78 | |
| ISWH300-480 | 300 |
540 720 900 |
150 200 250 |
31 28 24 |
75 | 980 |
79 81 80 |
|
| ISWH300-480A | 300 |
450 600 720 |
126 166 200 |
27.4 24 20.0 |
75 | 980 |
78 80 79 |
|
| ISWH300--480B | 300 |
400 540 650 |
111 150 180 |
24 21 17 |
55 | 980 | 79 | |
| ISWH300-315(I) | 300 |
650 950 1200 |
180.6 263.9 333.3 |
36 32 28 |
132 | 1450 | 82 | |
| ISWH300-315(I)A | 300 |
600 900 1150 |
166.7 250 320 |
32 28 24 |
110 | 1450 | 80 | |
| ISWH350-235 | 350 |
600 800 960 |
167 222 267 |
14 12.5 10.5 |
37 | 980 |
80 83 82 |
|
| ISWH350-235(I) | 350 |
800 1080 1350 |
222.2 300 375 |
20 16 12 |
75 | 980 |
80 83 82 |
|
| ISWH350-300 | 350 |
600 800 960 |
167 222 267 |
22.5 20 17.5 |
75 | 980 |
79 82 71 |
|
| ISWH350-315 | 350 |
600 800 960 |
167 222 267 |
35.5 32 28.5 |
90 | 980 | 84 | |
| ISWH350-400 | 350 |
600 800 960 |
167 222 267 |
55 50 45.5 |
160 | 980 | 83 | |
| ISWH400-300 | 400 |
920 1180 1300 |
255 328 361 |
23 19 16 |
90 | 980 | 78 | |
| ISWH400-315 | 400 |
950 1250 1500 |
264 347 416 |
32 28 24 |
132 | 980 | 76 | |
| ISWH500-235 | 500 |
1500 1800 2000 |
416 500 556 |
16 14 12 |
110 | 980 | 75 | |
| ISWH500-300 | 500 |
1400 1700 1900 |
388 472 528 |
22 20 18 |
132 | 980 | 80 | |
| ISWH500-315 | 500 |
1200 1550 1800 |
333 416 500 |
32 28 24 |
160 | 980 | 78 | |
點擊圖片放大
YG離心油泵
SNF襯氟管道泵
SAW濃硫酸離心泵
